Stainless Steel Membrane Filter Holder is constructed of stainless steel material, which is ready to-use units for laboratory research and Small scale process validation in the pharmaceutical industry.This filter has quick-install and thread connection modes.Inside and outside surface is electropolished finish,Sanitary grade.
Applications
- Laboratory Research
- Small scale process validation in the pharmaceutical industry
Specifications
| Surface Finish | |
| Finish Process Options | Electropolished |
| Polish Quality | Internal: Ra ≤ 0.4μm, External: Ra ≤ 0.8μm |
| Filtration Area | 17.3cm², 28.3cm², 63.6cm², 158.3cm² |
| Connection | |
| Inlet, Outlet | Tri-clamp 1″ |
| Port | Inner bore, 4mm Connects with 8mm pipe |
| Materials | |
| Shell Options | 316L Stainless Steel |
| C-clamp/Bolt Closure | 304 |
| eal Materials | Silicone, FKM, EPDM |
| Operating Conditions | |
| Design Pressure Options | 0.6MPa (90psi) |
| Max. Operating Temperature | 150℃ (302°F) |
Order Information
