Features
- Compact structure, easy to install
- Low pressure loss
- Integrated sealing technique, Integrated sealing technology reduces the risk of installation leakage
- 100% leak test
- 100% filter scan tested according to EN1822
Applications
- Purification equipment, such as laminar flow cover, transfer window, weighing room, clean table, etc
- Cleanrooms and equipment for semiconductor, electronics, flat panel display, precision machinery, pharmaceutical, medical, food and beverage, bioengineering, etc.


Material
| Filter frame | Extruded aluminum frame,galvanized frame, stainless steel frame |
| Media | Moisture-proof micro glass fibers (Import and domestic) |
| Filter efficiency | H13, H14, U15(EN1822@MPPS) |
| Sealant | Bi-component polyurethane |
| Separator | Hot-melt |
| Gasket | CR/EPDM/ Polyurethane foam sealant |
| Grille | Double-sided plastic spraying net |
| Max. temperature | 80℃(176°F) |
| Max. humidity | 100%RH |
