Hydrophilic PTFE Syringe Filters
- Avoid the expense and inconvenience of keeping a variety of filters on hand. Versatile filter for aqueous and aggressive organic solvent-based solutions.
- Accurate analysis. HPLC certified for low levels of UV-absorbing extractables.
- Low protein binding membrane.
- Easy filtration of particulate-laden samples with glass fiber prefilter version.
- No prewetting is required.
Applications
- Highly recommended for filtering HPLC samples.
- Available in 0.22 µm for UHPLC applications.
Specifications
| Pore Size | 0.22μm/0.45μm |
| Membrane | Hydrophilic PTFE |
Hydrophobic PTFE Syringe Filters
- Ideal for filtration of gas and/or organic solvents.
- Prevents spurious peaks on chromatograms for accurate experimental results.
- HPLC certified for low levels of UV-absorbing extractables.
Applications
- Filtering harsh chemicals.
- Moisture barrier for venting applications.
- HPLC/UHPLC Sample Preparation.
Specifications
| Pore Size | 0.22μm/0.45μm/1μm |
| Membrane | Hydrophobic PTFE |
Nylon Syringe Filters
- Excellent chemical compatibility with esters, bases, and alcohols.
- Low extractable
- Inherently hydrophilic: Saves time because no prewetting is required
Applications
- Good for cryoprotectants such as DMSO
- Filtration of aqueous biological solutions,alcoholic solutions
- HPLC/UHPLC Sample Preparation
- Not recommended for acids > 1 N or halogenated solvents
- Recommended for aqueous samples only
Specifications
| Pore Size | 0.22μm/0.45μm |
| Membrane | Nylon |
PES Syringe Filters
- Accurate results for the most sensitive analysis of ionic species.
- Low Protein Binding and extractable.
- High fiow rates.
Applications
- Specigically designed for IC applications
- Excellent filter selection for dissolution samples
- Low drug and protein binding for pharmaceutical filtration
- Recommended for aqueous samples only
Specifications
| Pore Size | 0.22μm/0.45μm/1μm |
| Membrane | PES |
Hydrophobic PVDF Syringe Filters
- Hydrophobic Membrane Compatible
- with a wide variety of Solvents
- Protects columns and instrumentation against particulate build up
Applications
- Offers excellent chemical compatibility, even with aggressive acids and alcohols
- HPLC/UHPLC Sample Preparation
- Not
- recommended for acetone, DMF, DMSO, or bases >6N
Specifications
| Pore Size | 0.22μm/0.45μm |
| Membrane | Hydrophobic PVDF |
Glass Fiber Syringe Filters
- Allowing quick and easy filtration of most difficult-to-filter samples
- Reduces clogging can use alone or in series with final membrane filter to increase fiow rate
- Ensures broad chemical compatibility with polypropylene housing.
Applications
- For difficult-to-Filter Samples
- HPLC/UHPLC Sample Preparation
- Removes particulate that interferes with UV/VIS spectrophotometric analysis
Specifications
| Pore Size | 0.22μm/0.45μm |
| Membrane | Glass Fiber |
MCE（Mixed Cellulose Ester） Syringe Filters
- Low Pressure Drop
- High partical retention
- Low Protein Binding and extractable
Applications
- Ideal for buffers,aqueous reagents and solutions
Specifications
| Pore Size | 0.22μm/0.45μm |
| Membrane | MCE (Mixed Cellulose Ester) |
Order Information
| Membrane | Pore Size | Diameter | Housing | IN/OUT Connection | Quantity Pack | Part Number |
| Hydrophobic PTFE Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PT0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PT0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PT0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PT0045N1A | |
| Hydrophilic PTFE Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PD0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PD0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PD0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PD0045N1A | |
| Nylon Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PC0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PC0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PC0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PC0045N1A | |
| PES Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PA0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PA0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PA0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PA0045N1A | |
| Hydrophobic PVDF Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PV0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PV0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PV0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PV0045N1A | |
| MCE Membrane | 0.22µm | 13mm | PP | N1 | 100 | 013PM0022N1A |
| 0.22µm | 25mm | PP | N1 | 100 | 025PM0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PM0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PM0045N1A | |
| Glass Fiber(GF) Membrane | 0.45µm | 13mm | PP | N1 | 100 | 013PM0045N1A |
| 0.45µm | 25mm | PP | N1 | 100 | 025PM0045N1A | |
| 0.22µm | 13mm | PP | N1 | 100 | 013PS0022N1A | |
| 0.22µm | 25mm | PP | N1 | 100 | 025PS0022N1A | |
| 0.45µm | 13mm | PP | N1 | 100 | 013PS0045N1A | |
| 0.45µm | 25mm | PP | N1 | 100 | 025PS0045N1A |
